CHEN Zebing, LI Wen, ZHU Yangli, WANG Xing, CHEN Haisheng
2025, 46(7): 2091-2105.
During the energy release phase of the compressed air energy storage (CAES) system, the air pressure in the storage device gradually decreases. When it falls below a certain threshold, the unit cannot maintain the rated total output power. To address this issue, the study proposes the applications of bypass systems in the CAES system expanders. In this paper, three types of bypass systems are designed for the expander unit of a CAES system: single-stage bypass systems (3 configurations), two-stage bypass systems (3 configurations), and three-stage bypass system (1 configuration), with a total of 7 configurations. By adjusting the openings of the main and bypass valves, the total inlet and outlet pressures of certain turbines are modified, thereby changing their mass flow rates and output powers to achieve the rated total output power. The results show that 5 configurations can achieve the desired performance. The three-stage bypass system enables the lowest terminal air pressure in the storage device, expanding the sliding pressure operation range of the unit. The optimal configuration is the two-stage bypass system that independently controls T1 and T2, which achieves the longest power generation duration and the highest energy density, representing a 71.25% improvement compared to the original unit. Therefore, adopting the bypass control methods can extend the power generation duration and increase the energy density of the CAES system.
